AM50E-2405SVZ

Active

aimtec

DC DC CONVERTER 5V 50W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER 5V 50W

Technical Specifications

Parameters and characteristics for this part

Specification	AM50E-2405SVZ

Applications	ITE (Commercial)
Current - Output (Max) [Max]	10 A
Efficiency	91 %
Features	Remote On/Off, Adjustable Output
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Power (Watts)	50 W
Size / Dimension [x]	50.8 mm
Size / Dimension [x]	2 in
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	0.47 "
Size / Dimension [z]	11.8 mm
Standard Number	62368-1
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	5 V

Part	Voltage - Input (Max) [Max]	Features	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Voltage - Isolation	Voltage - Output 1	Power (Watts)	Efficiency	Standard Number	Number of Outputs	Current - Output (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Type	Voltage - Input (Min) [Min]	Mounting Type	Package / Case
aimtec AM50E-2405SVZ	36 V	Adjustable Output Remote On/Off	-40 °C	105 ░C	ITE (Commercial)	1.5 kV	5 V	50 W	91 %	62368-1	1	10 A	25.4 mm	50.8 mm	0.47 "	11.8 mm	25.4 mm	2 in	Isolated Module	18 V	Through Hole
aimtec AM50E-2405S-NZ-K	36 V	Heat Sink Remote On/Off	-40 °C	65 °C	ITE (Commercial)	1.5 kV	5 V	50 W	93 %		1	10 A	25.4 mm	50.8 mm	0.64 in	16.3 mm	25.4 mm	2 in	Isolated Module	18 V	Through Hole	6-DIP Module
aimtec AM50E-2403SVZ	36 V	Adjustable Output Remote On/Off	-40 °C	105 ░C	ITE (Commercial)	1.5 kV	3.3 V	33 W	91 %	62368-1	1	10 A	25.4 mm	50.8 mm	0.47 "	11.8 mm	25.4 mm	2 in	Isolated Module	18 V	Through Hole
aimtec AM50E-4824S-NZ-K	75 V	Heat Sink Remote On/Off	-40 °C	65 °C	ITE (Commercial)	1.5 kV	24 V	50 W	93 %		1	2.083 A	25.4 mm	50.8 mm	0.64 in	16.3 mm	25.4 mm	2 in	Isolated Module	36 V	Through Hole	6-DIP Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 1 Output 5V 10A 18V - 36V Input
