RC1218JK-071RP
ActiveYAGEO
RES 1 OHM 5% 1W WIDE
Deep-Dive with AI
Search across all available documentation for this part.
RC1218JK-071RP
ActiveYAGEO
RES 1 OHM 5% 1W WIDE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | RC1218JK-071RP |
|---|---|
| Composition | Thick Film |
| Height - Seated (Max) [Max] | 0.026 in |
| Height - Seated (Max) [Max] | 0.65 mm |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 1218, Wide 1812 (4532 Metric) |
| Power (Watts) | 1 W |
| Ratings | 7C1, 100% Pb-Free, RoHS w/out Exemption |
| Resistance | 1 Ohms |
| Size / Dimension [x] | 0.122 " |
| Size / Dimension [x] | 3.1 mm |
| Size / Dimension [y] | 0.181 in |
| Size / Dimension [y] | 4.6 mm |
| Supplier Device Package | 1218 |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 4000 | $ 0.30 | |
Description
General part information
RC1218 Series
1 Ohms ±5% 1W Chip Resistor Wide 1812 (4532 Metric), 1218 Thick Film
