MD112S-12E
ActiveMicroPower Direct
DC-DC 12VIN 12VOUT 1W SIP UNREGU
Deep-Dive with AI
Search across all available documentation for this part.
MD112S-12E
ActiveMicroPower Direct
DC-DC 12VIN 12VOUT 1W SIP UNREGU
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MD112S-12E |
|---|---|
| Applications | Industrial |
| Approval Agency | CE, UKCA, UL |
| Current - Output (Max) [Max] | 83 mA |
| Efficiency | 80 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 105 C |
| Operating Temperature [Min] | -40 °C |
| Size / Dimension [x] | 0.77 in |
| Size / Dimension [x] | 19.7 mm |
| Size / Dimension [y] | 0.24 " |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [z] | 10.2 mm |
| Size / Dimension [z] | 0.38 in |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 13.2 V |
| Voltage - Input (Min) [Min] | 10.8 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
MD112S-12E
Isolated Module DC DC Converter 1 Output 12V 83mA 10.8V - 13.2V Input
