Technical Specifications
Parameters and characteristics for this part
| Specification | TPL740F33-FR |
|---|---|
| Control Features | Enable |
| Current - Output | 500 mA |
| Current - Quiescent (Iq) | 200 µA |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Positive |
| Output Type | 1.81 mOhm |
| Package / Case | 4-XDFN Exposed Pad |
| Protection Features | Short Circuit, Over Temperature, Under Voltage Lockout (UVLO), Over Current |
| PSRR [Max] | 40 dB |
| PSRR [Min] | 60 dB |
| Supplier Device Package | 4-DFN (1x1) |
| Voltage - Input (Max) [Max] | 5.5 V |
| Voltage - Output (Min/Fixed) | 3.3 V |
| Voltage Dropout (Max) [Max] | 0.4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.49 | |
| 10 | $ 0.40 | |||
| 25 | $ 0.36 | |||
| 100 | $ 0.27 | |||
| 250 | $ 0.25 | |||
| 500 | $ 0.20 | |||
| 1000 | $ 0.15 | |||
| 2500 | $ 0.14 | |||
| 5000 | $ 0.13 | |||
| Digi-Reel® | 1 | $ 0.49 | ||
| 10 | $ 0.40 | |||
| 25 | $ 0.36 | |||
| 100 | $ 0.27 | |||
| 250 | $ 0.25 | |||
| 500 | $ 0.20 | |||
| 1000 | $ 0.15 | |||
| 2500 | $ 0.14 | |||
| 5000 | $ 0.13 | |||
| Tape & Reel (TR) | 12000 | $ 0.12 | ||
| 24000 | $ 0.11 | |||
| 60000 | $ 0.11 | |||
Description
General part information
TPL740F33-FR
Linear Voltage Regulator IC Positive Fixed 1 Output 500mA 4-DFN (1x1)
