UH035M101F12PE50S00A
ActiveSuscon
CAP ALUM 100UF 20% 35V RADIAL TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UH035M101F12PE50S00A
ActiveSuscon
CAP ALUM 100UF 20% 35V RADIAL TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UH035M101F12PE50S00A |
|---|---|
| Applications | Automotive |
| Capacitance | 100 µF |
| Height - Seated (Max) [Max] [z] | 12 mm |
| Height - Seated (Max) [Max] [z] | 0.472 " |
| Impedance | 220 mOhms |
| Lead Spacing | 3.5 mm |
| Lead Spacing | 0.138 in |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 130 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Radial, Can |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current @ High Frequency | 360 mA |
| Ripple Current @ Low Frequency | 270 mA |
| Size / Dimension [diameter] | 0.315 " |
| Size / Dimension [diameter] | 8 mm |
| Tolerance | 20 % |
| Voltage - Rated | 35 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 5 | $ 0.23 | |
| 50 | $ 0.19 | |||
| 100 | $ 0.16 | |||
| 500 | $ 0.13 | |||
| 1000 | $ 0.11 | |||
Description
General part information
UH035M101F12PE50S00A
100 µF 35 V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 130°C
