CS53B-F3050CQ18-19.200M-TR
ActiveTransko Electronics, Inc.
19.200MHZ CRYSTAL, 18PF LOAD, FU
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CS53B-F3050CQ18-19.200M-TR |
|---|---|
| ESR (Equivalent Series Resistance) | 50 Ohms |
| Frequency | 19.2 MHz |
| Frequency Stability | 50 ppm |
| Frequency Tolerance | 30 ppm |
| Height - Seated (Max) [Max] | 1.2 mm |
| Height - Seated (Max) [Max] | 0.047 in |
| Load Capacitance | 18 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 2-SMD, No Lead |
| Size / Dimension [x] | 0.197 in |
| Size / Dimension [x] | 5 mm |
| Size / Dimension [y] | 0.126 " |
| Size / Dimension [y] | 3.2 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1000 | $ 0.25 | |
Description
General part information
CS53B-F3050CQ18-19.200M-TR
19.2 MHz ±30ppm Crystal 18pF 50 Ohms 2-SMD, No Lead
