MA624S-05ERU
ActiveMicroPower Direct
DC-DC 24VIN 5VOUT 6W DIP REGULAT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MA624S-05ERU
ActiveMicroPower Direct
DC-DC 24VIN 5VOUT 6W DIP REGULAT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MA624S-05ERU |
|---|---|
| Applications | Industrial |
| Approval Agency | UL, cUL |
| Current - Output (Max) [Max] | 1.2 A |
| Efficiency | 83 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 6 W |
| Size / Dimension [x] | 32 mm |
| Size / Dimension [x] | 1.26 in |
| Size / Dimension [y] | 19.9 mm |
| Size / Dimension [y] | 0.78 in |
| Size / Dimension [z] | 11.2 mm |
| Size / Dimension [z] | 0.44 " |
| Standard Number | 60950-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 13.00 | |
| 10 | $ 12.50 | |||
| 25 | $ 12.10 | |||
| 50 | $ 11.70 | |||
| 100 | $ 11.35 | |||
Description
General part information
MA624S-05ERU
Isolated Module DC DC Converter 1 Output 5V 1.2A 9V - 36V Input
