MST 1A 300V
ActiveConquer
MICRO FUSE, RADIAL, SLOW BLOW, 1
Deep-Dive with AI
Search across all available documentation for this part.
MST 1A 300V
ActiveConquer
MICRO FUSE, RADIAL, SLOW BLOW, 1
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MST 1A 300V |
|---|---|
| Applications | Electrical, Industrial |
| Approval Agency | PSE, cURus, TUV |
| Breaking Capacity @ Rated Voltage | 50 A |
| DC Cold Resistance | 0.075 Ohms |
| Fuse Type | Board Mount |
| Melting I²t | 8.73 |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Box |
| Response Time | Slow Blow |
| Size / Dimension [x] | 0.329 in |
| Size / Dimension [x] | 8.35 mm |
| Size / Dimension [y] | 0.169 in |
| Size / Dimension [y] | 4.3 mm |
| Size / Dimension [z] | 7.7 mm |
| Size / Dimension [z] | 0.303 in |
| Voltage Rating - AC | 300 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.82 | |
| 5 | $ 0.79 | |||
| 10 | $ 0.77 | |||
| 50 | $ 0.65 | |||
| 100 | $ 0.54 | |||
| 250 | $ 0.49 | |||
| 500 | $ 0.41 | |||
| Tape & Box (TB) | 1000 | $ 0.40 | ||
| 2000 | $ 0.37 | |||
| 3000 | $ 0.35 | |||
| 5000 | $ 0.33 | |||
| 7000 | $ 0.32 | |||
| 10000 | $ 0.30 | |||
| 25000 | $ 0.30 | |||
Description
General part information
MST 1A 300V
1A 300 VAC Fuse Board Mount Through Hole
Documents
Technical documentation and resources
No documents available
