MPE-15SV-05
ActiveMicroPower Direct
AC-DC 85-305VAC 5VOUT 15W ENCLOS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MPE-15SV-05
ActiveMicroPower Direct
AC-DC 85-305VAC 5VOUT 15W ENCLOS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MPE-15SV-05 |
|---|---|
| Applications | Industrial |
| Approval Agency | CE, UKCA, UL |
| Efficiency | 78 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 °C |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 78 mm |
| Size / Dimension [x] | 3.07 in |
| Size / Dimension [y] | 55 mm |
| Size / Dimension [y] | 2.17 in |
| Size / Dimension [z] | 25 mm |
| Size / Dimension [z] | 0.98 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 11.50 | |
| 10 | $ 11.05 | |||
| 25 | $ 10.85 | |||
| 50 | $ 10.60 | |||
| 100 | $ 10.35 | |||
Description
General part information
MPE-15SV-05
Enclosed AC DC Converters 1 Output 5V Input
