XTL901200-T257-026
ActiveSiward
CRYSTAL 1.6 X 1.2MM 32MHZ +/-10P
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XTL901200-T257-026
ActiveSiward
CRYSTAL 1.6 X 1.2MM 32MHZ +/-10P
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XTL901200-T257-026 |
|---|---|
| Frequency | 32 MHz |
| Frequency Stability | 20 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] | 0.014 in |
| Height - Seated (Max) [Max] | 0.35 mm |
| Load Capacitance | 8 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 1.6 mm |
| Size / Dimension [x] | 0.063 in |
| Size / Dimension [y] | 0.047 in |
| Size / Dimension [y] | 1.2 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.73 | |
| 10 | $ 0.63 | |||
| 50 | $ 0.57 | |||
| 100 | $ 0.55 | |||
| 500 | $ 0.50 | |||
| Digi-Reel® | 1 | $ 0.73 | ||
| 10 | $ 0.63 | |||
| 50 | $ 0.57 | |||
| 100 | $ 0.55 | |||
| 500 | $ 0.50 | |||
| Tape & Reel (TR) | 1000 | $ 0.48 | ||
| 2000 | $ 0.46 | |||
| 3000 | $ 0.45 | |||
| 5000 | $ 0.43 | |||
| 7000 | $ 0.43 | |||
| 10000 | $ 0.42 | |||
| 25000 | $ 0.39 | |||
Description
General part information
XTL901200-T257-026
32 MHz ±10ppm Crystal 8pF 4-SMD, No Lead
