AK1100/2-5.0-GREEN
ActivePTR HARTMANN
TERM BLK PLUG 2POS 5.0MM 0.197"
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AK1100/2-5.0-GREEN |
|---|---|
| Color | Green |
| Contact Material | Bronze |
| Features | Retention Latches (Wire Side) |
| Insulation Height | 1.024 " |
| Insulation Height | 26.01 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Plug Wire Entry | 90 ° |
| Positions Per Level | 2 |
| Screw Size | M3 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | 4.4 Lb-In |
| Torque - Screw | 0.5 Nm |
| Type | Plug, Female Sockets |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 28 AWG |
| Wire Gauge or Range - AWG [Min] | 10 AWG |
| Wire Gauge or Range - mm² [Max] | 4 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² |
| Wire Strip Length | 7 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 1.57 | |
| 10 | $ 1.11 | |||
| 25 | $ 1.03 | |||
| 50 | $ 0.94 | |||
| 200 | $ 0.93 | |||
| 400 | $ 0.79 | |||
| 600 | $ 0.75 | |||
| 1000 | $ 0.66 | |||
| 5000 | $ 0.54 | |||
Description
General part information
AK1100/2-5.0-GREEN
2 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 90° Free Hanging (In-Line)
