SEH 30A 125V (G)
ActiveConquer
FUSE BRD MT 30A 125VAC 100VDC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SEH 30A 125V (G) |
|---|---|
| Breaking Capacity @ Rated Voltage | 100 A, 100 A |
| Current Rating (Amps) | 30 A |
| DC Cold Resistance | 0.0016 Ohms |
| Fuse Type | Board Mount |
| Melting I²t | 101 |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 2-SMD, Square End Block |
| Size / Dimension [x] | 10.1 mm |
| Size / Dimension [x] | 0.398 in |
| Size / Dimension [y] | 0.122 in |
| Size / Dimension [y] | 3.1 mm |
| Size / Dimension [z] | 0.122 in |
| Size / Dimension [z] | 3.1 mm |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 100 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 4.52 | |
| 5 | $ 4.37 | |||
| 10 | $ 4.22 | |||
| 50 | $ 3.32 | |||
| 100 | $ 2.71 | |||
| 250 | $ 2.64 | |||
| 500 | $ 2.26 | |||
| 1000 | $ 2.11 | |||
| Digi-Reel® | 1 | $ 4.52 | ||
| 5 | $ 4.37 | |||
| 10 | $ 4.22 | |||
| 50 | $ 3.32 | |||
| 100 | $ 2.71 | |||
| 250 | $ 2.64 | |||
| 500 | $ 2.26 | |||
| 1000 | $ 2.11 | |||
| Tape & Reel (TR) | 2500 | $ 1.87 | ||
| 5000 | $ 1.87 | |||
Description
General part information
SEH 30A 125V (G)
30 A 125 V AC 100 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
