ENH-2180
ActiveEnhance Electronics
AC/DC CNVRTR 3.3V 5V +/-12V 978W
Deep-Dive with AI
Search across all available documentation for this part.
ENH-2180
ActiveEnhance Electronics
AC/DC CNVRTR 3.3V 5V +/-12V 978W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ENH-2180 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, NEMKO, CCC, cURus, CB, FCC, cUL |
| Current - Output 1 | 22 A |
| Current - Output 2 | 22 A |
| Current - Output 3 | 66 A |
| Current - Output 4 | 300 mA |
| Efficiency | 87 % |
| Features | Standby Output, Universal Input, PFC |
| Mounting Type | Chassis Mount |
| Number of Outputs | 4 |
| Power (Watts) | 978 W |
| Size / Dimension [x] | 7.87 in |
| Size / Dimension [x] | 199.9 mm |
| Size / Dimension [y] | 3.94 in |
| Size / Dimension [y] | 100.1 mm |
| Size / Dimension [z] | 70.1 mm |
| Size / Dimension [z] | 2.76 in |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output 1 | 3.3 V |
| Voltage - Output 2 | 5 V |
| Voltage - Output 3 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 270.00 | |
Description
General part information
ENH-2180
Enclosed AC DC Converters 4 Output 3.3V 5V 12V -12V 90 ~ 264 VAC Input
Documents
Technical documentation and resources
No documents available
