DST-3-10
ActiveSignal Transformer
PWR XFMR LAMINATED 2.4VA TH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | DST-3-10 |
|---|---|
| Center Tap | False |
| Current - Output (Max) [Max] | 500 mA, 250 mA |
| Height - Seated (Max) [Max] [z] | 30.8 mm |
| Mounting Type | Through Hole |
| Power - Max [Max] | 2.4 VA |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Size / Dimension [x] | 34.9 mm |
| Size / Dimension [y] | 28.6 mm |
| Termination Style | PC Pin |
| Type | Laminated Core |
| Voltage - Isolation | 2500 Vrms |
| Voltage - Primary | 115 V, 230 V |
| Voltage - Secondary (Full Load) [custom] | 5 V |
| Voltage - Secondary (Full Load) [custom] | 10 V |
| Weight | 113.4 g |
| Weight | 0.25 lbs |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 12.11 | |
| 10 | $ 8.95 | |||
| 100 | $ 7.76 | |||
| 1000 | $ 7.43 | |||
Description
General part information
DST-3-10
PWR XFMR LAMINATED 2.4VA TH
