720-6300
ActiveTRUMETER
PANEL MOUNT TIMER, MODEL 720, DIGITAL, 85 VAC, 500 VAC
Deep-Dive with AI
Search across all available documentation for this part.
720-6300
ActiveTRUMETER
PANEL MOUNT TIMER, MODEL 720, DIGITAL, 85 VAC, 500 VAC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 720-6300 |
|---|---|
| Display Characters - Height [y] | 0.315 in |
| Display Characters - Height [y] | 8 mm |
| Display Type | LCD - Black Characters |
| Ingress Protection | IP66 |
| Input Type | Voltage |
| Number of Characters Per Row | 8 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Panel Cutout Dimensions [x] | 45.5 mm |
| Panel Cutout Dimensions [y] | 22.6 mm |
| Termination Style | Screw Terminal |
| Type | Time Counter (Hour Meter) |
| Voltage - Supply [Max] | 500 VAC |
| Voltage - Supply [Min] | 85 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
720-6300
The 720-6300 is a 500VAC Electronic LCD Hour Meter with large 8-digit display, (9999999.9) 0.32-inch (8mm) high with an input operating voltage of 85-500VAC. The front of the unit is totally sealed and is housed in a rugged steel enclosure and self-powered (internal lithium battery).
