L201203-303MHF
ActiveITG Electronics, Inc.
FIXED IND 30MH 1.2A TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
L201203-303MHF
ActiveITG Electronics, Inc.
FIXED IND 30MH 1.2A TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | L201203-303MHF |
|---|---|
| Current - Saturation (Isat) | 350 mA |
| Current Rating (Amps) | 1.2 A |
| Inductance | 30 mH |
| Inductance Frequency - Test | 10 kHz |
| Material - Core | Alloy Powder |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 130 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Vertical Cylinder, Radial |
| Package / Case | 4 Leads |
| Shielding | Unshielded |
| Size / Dimension [x] | 44 mm |
| Size / Dimension [x] | 1.732 " |
| Size / Dimension [y] | 20.6 mm |
| Size / Dimension [y] | 0.811 " |
| Tolerance | 20 % |
| Type | Toroidal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 12 | $ 9.00 | |
Description
General part information
L201203-303MHF
30 mH Unshielded Toroidal Inductor 1.2 A Radial, Vertical Cylinder, 4 Leads (Open)
