159-2801-020
UnknownAmphenol Spectra-Strip
CBL RIBN 20COND 0.05 BLACK 25'
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
159-2801-020
UnknownAmphenol Spectra-Strip
CBL RIBN 20COND 0.05 BLACK 25'
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 159-2801-020 |
|---|---|
| Cable Type | Round Jacket, Flat Cable |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 36 AWG |
| Current Rating (Amps) | 1.3 A |
| First Conductor Mark | Red |
| Insulation Resistance | 10 GOhm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Black |
| Length | 25 ft |
| Length | 7.62 m |
| Length [x] | 3.05 m |
| Length [x] | 10 ft |
| Number of Conductors | 20 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 0.05 in |
| Pitch [x] | 1.27 mm |
| Ribbon Thickness | 0.89 mm |
| Ribbon Thickness | 0.035 in |
| Ribbon Width | 1 in |
| Ribbon Width | 25.4 mm |
| Shielding | Shielded |
| Voltage | 300 V |
| Wire Gauge | 28 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 37.42 | |
| 1 | $ 87.90 | |||
Description
General part information
159-2801-020
Flat Ribbon Cable Black 20 Conductors 0.050" (1.27mm) Flat Cable, Round Jacket 25.0' (7.62m)
