LP1K0901BD
ActiveSQUARE D BY SCHNEIDER ELECTRIC
CONTACTOR, 9 A, DIN RAIL, PANEL, 690 VAC, 3PST-NO, 3 POLE, 4 KW
Deep-Dive with AI
Search across all available documentation for this part.
LP1K0901BD
ActiveSQUARE D BY SCHNEIDER ELECTRIC
CONTACTOR, 9 A, DIN RAIL, PANEL, 690 VAC, 3PST-NO, 3 POLE, 4 KW
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | LP1K0901BD |
|---|---|
| Coil Voltage | 24 VDC |
| Contact Form | 3PST-NO (3 Form A) |
| Contact Rating (Current) | 9 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount, DIN Rail |
| Must Operate Voltage | 19.2 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 10 ms |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -25 °C |
| Switching Voltage | 690 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
LP1K0901BD
CONTACTOR, 9 A, DIN RAIL, PANEL, 690 VAC, 3PST-NO, 3 POLE, 4 KW
Documents
Technical documentation and resources
