BW08030012BM-6
ActiveYS TECH USA
FAN BLOWER 75X30MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
BW08030012BM-6
ActiveYS TECH USA
FAN BLOWER 75X30MM 12VDC WIRE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | BW08030012BM-6 |
|---|---|
| Air Flow | 0.342 mł/min |
| Air Flow | 12.2 CFM |
| Bearing Type | Ball |
| Current Rating (Amps) | 0.19 A |
| Fan Type | Blower |
| Features | Auto Restart |
| Lifetime @ Temp. | 80000 Hrs |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Noise | 42 dB |
| Power (Watts) | 2.28 W |
| RPM | 3000 RPM |
| Size / Dimension | Square/Rounded |
| Size / Dimension [x] | 75 mm |
| Size / Dimension [z] | 75 mm |
| Static Pressure | 0.406 in H2O |
| Static Pressure | 101.1 Pa |
| Termination | 2 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.2 VDC |
| Voltage Range [Min] | 7 V |
| Width [y] | 30 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 10.28 | |
| 10 | $ 9.16 | |||
| 25 | $ 8.76 | |||
| 50 | $ 8.46 | |||
| 100 | $ 8.17 | |||
| 250 | $ 7.80 | |||
| 500 | $ 7.54 | |||
| 1000 | $ 7.28 | |||
Description
General part information
BW08030012BM-6
Fan Blower 12VDC Square/Rounded - 75mm L x 75mm H Ball 12.2 CFM (0.342mł/min) 2 Wire Leads
