DS87C530-ENL
ActiveDallas Semiconductor
IC MCU 8BIT 16KB OTP 52PLCC
Deep-Dive with AI
Search across all available documentation for this part.
DS87C530-ENL
ActiveDallas Semiconductor
IC MCU 8BIT 16KB OTP 52PLCC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | DS87C530-ENL |
|---|---|
| Connectivity | UART/USART, SIO, EBI/EMI |
| Core Processor | 8051 |
| Core Size | 8-Bit |
| Mounting Type | Surface Mount |
| Number of I/O | 32 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Oscillator Type | External |
| Package / Case | 52-LCC (J-Lead) |
| Program Memory Size | 16 KB |
| Program Memory Type | OTP |
| RAM Size | 1 K |
| Speed | 33 MHz |
| Supplier Device Package | 52-PLCC |
| Supplier Device Package [x] | 19.12 |
| Supplier Device Package [y] | 19.12 |
| Voltage - Supply (Vcc/Vdd) [Max] | 5.5 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 9 | $ 36.22 | |
Description
General part information
DS87C530-ENL
8051 - Microcontroller IC 8-Bit 33MHz 16KB (16K x 8) OTP 52-PLCC (19.12x19.12)
Documents
Technical documentation and resources
No documents available
