RXC35P3QX
ActiveRincon Power
350A DC CONTACTOR, 1000V, PCB MO
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RXC35P3QX
ActiveRincon Power
350A DC CONTACTOR, 1000V, PCB MO
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RXC35P3QX |
|---|---|
| Coil Current | 90 mA |
| Coil Power | 2.2 W |
| Coil Voltage | 24 VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Rating (Current) | 350 A |
| Features | Sealed - Hermetically, Economizer |
| Mounting Type | Through Hole |
| Must Operate Voltage | 15 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 25 ms |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -45 °C |
| Release Time | 10 ms |
| Switching Voltage [Max] | 1000 VDC |
| Termination Style | Stud, PC Pins |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 151.10 | |
| 5 | $ 145.90 | |||
| 20 | $ 142.00 | |||
Description
General part information
RXC35P3QX
350A DC CONTACTOR, 1000V, PCB MO
