AK130/2-5.0-GREY
ActivePTR HARTMANN
TERM BLK PLUG 2POS 5.0MM 0.197"
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AK130/2-5.0-GREY
ActivePTR HARTMANN
TERM BLK PLUG 2POS 5.0MM 0.197"
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AK130/2-5.0-GREY |
|---|---|
| Color | Gray |
| Contact Material | Copper Alloy |
| Current - UL | 8 A |
| Features | Interlocking (Side) |
| Insulation Height | 0.425 in |
| Insulation Height | 10.8 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Plug Wire Entry | 90 ° |
| Positions Per Level | 2 |
| Screw Size | M2.6 |
| Termination Style | Screw - Leaf Spring, Wire Guard |
| Torque - Screw | 0.45 Nm |
| Torque - Screw | 4 Lb-In |
| Type | Plug for Unshrouded Header |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 22 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.14 mm² |
| Wire Strip Length | 6 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 0.71 | |
| 10 | $ 0.44 | |||
| 25 | $ 0.38 | |||
| 50 | $ 0.34 | |||
| 100 | $ 0.33 | |||
| 250 | $ 0.28 | |||
| 500 | $ 0.27 | |||
| 1000 | $ 0.24 | |||
| 5000 | $ 0.19 | |||
Description
General part information
AK130/2-5.0-GREY
2 Position Terminal Block Plug for Unshrouded Header 0.197" (5.00mm) 90° Free Hanging (In-Line)
