CF50S-823-JTW
ActiveRCD Components
RES CARB FILM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CF50S-823-JTW
ActiveRCD Components
RES CARB FILM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CF50S-823-JTW |
|---|---|
| Composition | Carbon Film |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial |
| Power (Watts) | 0.5 W |
| Power (Watts) | 0.5 W |
| Resistance | 82 kOhms |
| Size / Dimension [diameter] | 0.126 in |
| Size / Dimension [diameter] | 3.2 mm |
| Size / Dimension [x] | 0.354 " |
| Size / Dimension [x] | 9 mm |
| Supplier Device Package | Axial |
| Tolerance | 5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 4000 | $ 0.03 | |
Description
General part information
CF50S-823-JTW
82 kOhms ±5% 0.5W, 1/2W Through Hole Resistor Axial Carbon Film
Documents
Technical documentation and resources
