1794
ObsoleteB&K PRECISION
POWER SPLY DC LINEAR 0-32V 0-30A
Deep-Dive with AI
Search across all available documentation for this part.
1794
ObsoleteB&K PRECISION
POWER SPLY DC LINEAR 0-32V 0-30A
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1794 |
|---|---|
| Current - Output [Max] | 30 A |
| Current - Output [Min] | 0 A |
| Current Regulation - Line [custom] | 0.05 %, 10 mA |
| Current Regulation - Load | 0.05 %, 10 mA |
| Display Type | LED |
| Features | Regulated |
| Number of Characters | 2 |
| Number of Characters | 3 |
| Number of Outputs | 1 |
| Ripple | 1 mV |
| Size / Dimension [x] | 15.75 in |
| Size / Dimension [x] | 400.05 mm |
| Size / Dimension [y] | 482.6 mm |
| Size / Dimension [y] | 19 in |
| Size / Dimension [z] | 5.25 in |
| Size / Dimension [z] | 133.35 mm |
| Type | Rack Mount (AC to DC) |
| Voltage - Output [Max] | 32 VDC |
| Voltage - Output [Min] | 0 VDC |
| Voltage - Supply | 115 VAC |
| Voltage Regulation - Load | 0.01 %, 2 mV |
| Weight | 50 lbs |
| Weight | 22.7 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
1794
0 ~ 32VDC Output Rack Mount (AC to DC) Power Supply LED 0 ~ 30A Output Features Regulated
Documents
Technical documentation and resources
No documents available
