HPR4006803Z1K
ActiveNexTek
HIGH-CURRENT FEEDTHROUGH FILTER,
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HPR4006803Z1K
ActiveNexTek
HIGH-CURRENT FEEDTHROUGH FILTER,
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HPR4006803Z1K |
|---|---|
| Current | 400 A |
| Mounting Type | Bolt Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial - Threaded Terminals |
| Size / Dimension [diameter] | 1.311 inches |
| Size / Dimension [diameter] | 33.3 mm |
| Size / Dimension [x] | 93 mm |
| Size / Dimension [x] | 3.661 inches |
| Values | 0.068 µF |
| Voltage - Rated | 1 kV |
| Voltage - Rated | 1000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 136.36 | |
| 10 | $ 111.18 | |||
| 25 | $ 104.00 | |||
Description
General part information
HPR4006803Z1K
EMI Filter Order Channel C = 0.068µF 400 A Axial - Threaded Terminals
