T3DSO2204
ObsoleteTeledyne LeCroy
DSO 200MHZ 2GS/S INTERLEAVED 4CH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
T3DSO2204
ObsoleteTeledyne LeCroy
DSO 200MHZ 2GS/S INTERLEAVED 4CH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | T3DSO2204 |
|---|---|
| Bandwidth | 200 MHz |
| Channels | 4 Analog |
| Display Type | LCD - Color |
| Function | Record, Trend |
| Includes | Power Cord, USB Adapter/Cable |
| Input Impedance | 1 M |
| Interface | USB, RS232 |
| Memory Size | 280 Mpts |
| Rise Time (Typ) | 1.7 ns |
| Sampling Rate (Per Second) | 2 G |
| Type | Bench, Digital |
| Voltage - Input (Max) [Max] | 240 V |
| Voltage - Supply [Max] | 240 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
T3DSO2204
200 MHz Bench, Digital Oscilloscopes RS232, USB Interface LCD - Color Display 4 Analog Channel 240V Record, Trend
