PT5112A
ObsoleteTexas Instruments
DC DC CONVERTER 8V 8W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PT5112A
ObsoleteTexas Instruments
DC DC CONVERTER 8V 8W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PT5112A |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 1 A |
| Efficiency | 91 % |
| Features | OCP, OTP |
| Mounting Type | Through Hole, Right Angle |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 3-SIP Module |
| Power (Watts) | 8 W |
| Size / Dimension [x] | 1 in |
| Size / Dimension [x] | 25.4 mm |
| Size / Dimension [y] | 1.02 " |
| Size / Dimension [y] | 25.9 mm |
| Size / Dimension [z] | 9.7 mm |
| Size / Dimension [z] | 0.38 in |
| Type | Linear Regulator Replacement |
| Voltage - Input (Max) [Max] | 38 V |
| Voltage - Output 1 | 8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
PT5112A
Linear Regulator Replacement DC DC Converter 1 Output 8V 1A 12V - 38V Input
