7U320000C06GJMSC
ActiveShenzhen Crystal Technology Industrial Co
QUARTZ CRYSTAL 32 MHZ, 10/10
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
7U320000C06GJMSC
ActiveShenzhen Crystal Technology Industrial Co
QUARTZ CRYSTAL 32 MHZ, 10/10
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 7U320000C06GJMSC |
|---|---|
| ESR (Equivalent Series Resistance) | 60 Ohms |
| Frequency | 32 MHz |
| Frequency Stability | 10 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] [z] | 0.8 mm |
| Height - Seated (Max) [Max] [z] | 0.031 " |
| Load Capacitance | 10 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -30 ░C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 3.2 mm |
| Size / Dimension [x] | 0.126 in |
| Size / Dimension [y] | 2.5 mm |
| Size / Dimension [y] | 0.098 in |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.52 | |
| 10 | $ 0.44 | |||
| 50 | $ 0.39 | |||
| 100 | $ 0.35 | |||
| 500 | $ 0.33 | |||
| 1000 | $ 0.28 | |||
| Digi-Reel® | 1 | $ 0.52 | ||
| 10 | $ 0.44 | |||
| 50 | $ 0.39 | |||
| 100 | $ 0.35 | |||
| 500 | $ 0.33 | |||
| 1000 | $ 0.28 | |||
| Strip | 3000 | $ 0.26 | ||
| 6000 | $ 0.25 | |||
| 15000 | $ 0.24 | |||
Description
General part information
7U320000C06GJMSC
32 MHz ±10ppm Crystal 10pF 60 Ohms 4-SMD, No Lead
