31107110
ActiveMETZ CONNECT USA Inc.
SCREW TYPE TERMINAL BLOCK, PLUG,
Deep-Dive with AI
Search across all available documentation for this part.
31107110
ActiveMETZ CONNECT USA Inc.
SCREW TYPE TERMINAL BLOCK, PLUG,
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 31107110 |
|---|---|
| Color | Black |
| Contact Material | Copper Tin |
| Contact Mating Finish | Tin |
| Current - UL | 10 A |
| Insulation Height | 12.8 mm |
| Insulation Height | 0.504 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 10 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Plug Wire Entry | 90 ° |
| Positions Per Level | 10 |
| Screw Size | M3 |
| Termination Style | Screw - Leaf Spring, Wire Guard |
| Torque - Screw | 6 Lb-In |
| Torque - Screw | 0.68 Nm |
| Type | Plug for Unshrouded Header |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 28 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.08 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 100 | $ 4.64 | |
Description
General part information
31107110
10 Position Terminal Block Plug for Unshrouded Header 0.197" (5.00mm) 90° Free Hanging (In-Line)
Documents
Technical documentation and resources
No documents available
