OFM-0105/M
ActiveAstrodyne TDI
AC/DC CONVERTER 24V 10W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OFM-0105/M
ActiveAstrodyne TDI
AC/DC CONVERTER 24V 10W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | OFM-0105/M |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output 1 | 420 mA |
| Efficiency | 81 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Power (Watts) | 10 W |
| Standard Number | 60950-1 |
| Type | Open Frame |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 5 | $ 66.33 | |
| 10 | $ 60.30 | |||
| 25 | $ 54.82 | |||
Description
General part information
OFM-0105/M
Open Frame AC DC Converters 1 Output 24V 90 ~ 264 VAC Input
