NW-PA-S-100-A01
ActiveNuWaves RF Solutions
IC RF AMP GPS 2GHZ-2.5GHZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NW-PA-S-100-A01 |
|---|---|
| Current - Supply | 11.5 A |
| Frequency [Max] | 2.5 GHz |
| Frequency [Min] | 2 GHz |
| Gain | 28 dBi |
| P1dB | 38 dBm |
| Package / Case | Module, SMA Connectors |
| RF Type | General Purpose |
| Voltage - Supply [Max] | 32 VDC |
| Voltage - Supply [Min] | 26 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 12729.00 | |
Description
General part information
NW-PA-S-100-A01
RF Amplifier IC General Purpose 2GHz ~ 2.5GHz
