10CP552
ActiveTransData, Inc.
SINGLE PHASE CURRENT TRANSDUCER
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
10CP552
ActiveTransData, Inc.
SINGLE PHASE CURRENT TRANSDUCER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 10CP552 |
|---|---|
| Accuracy | 0.2 % |
| Input Range [Max] | 10 A |
| Input Range [Min] | 0 A |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Output [Max] | 20 mA |
| Output [Min] | 4 mA |
| Response Time | 400 ms |
| Termination Style | Screw Terminal |
| Type | Current Transducer |
| Voltage - Supply [Max] | 130 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 800.00 | |
Description
General part information
10CP552
Current Transducer 0 ~ 10A Input 4 ~ 20mA Output 100 ~ 130VAC Chassis Mount
