908 346
ActiveDEHN
SPD TYPE 1 385/565VAC MCOV 3POLE
Deep-Dive with AI
Search across all available documentation for this part.
908 346
ActiveDEHN
SPD TYPE 1 385/565VAC MCOV 3POLE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 908 346 |
|---|---|
| Approval Agency | CSA, UL |
| Current - Discharge (Max) (8/20µS) [Max] | 50 kA |
| Current - Discharge (Nom) (8/20µS) | 20 kA |
| Features | Remote Signaling Contacts, Visual Life Indicator |
| Form | Base + Module |
| Mounting Type | DIN Rail |
| Number of Poles | 3 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Type | Type 1 |
| Voltage - Continuous Operating (Max) (MCOV) | 770 VAC, 180 VAC, 565 VAC, 385 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 286.67 | |
| 10 | $ 268.75 | |||
| 25 | $ 252.94 | |||
| 50 | $ 238.89 | |||
Description
General part information
908 346
SPD TYPE 1 385/565VAC MCOV 3POLE
Documents
Technical documentation and resources
No documents available
