SM2011A-4R7MHF
ActiveITG Electronics, Inc.
MOLDED INDUCTOR4.7UH 52.2M 5.5A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SM2011A-4R7MHF
ActiveITG Electronics, Inc.
MOLDED INDUCTOR4.7UH 52.2M 5.5A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SM2011A-4R7MHF |
|---|---|
| Current - Saturation (Isat) | 5.5 A |
| Current Rating (Amps) | 4.5 A |
| DC Resistance (DCR) | 57.5 mOhm |
| Height - Seated (Max) | 3 mm |
| Height - Seated (Max) [Max] | 0.118 in |
| Inductance | 4.7 ÁH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension [x] | 5.4 mm |
| Size / Dimension [x] | 0.213 " |
| Size / Dimension [y] | 5.2 mm |
| Size / Dimension [y] | 0.205 " |
| Tolerance | 20 % |
| Type | Molded |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.48 | |
| 10 | $ 0.46 | |||
| 20 | $ 0.44 | |||
| 40 | $ 0.42 | |||
Description
General part information
SM2011A-4R7MHF
4.7 µH Unshielded Molded Inductor 4.5 A 57.5mOhm Max Nonstandard
