MOC3032XSM
ActiveIsocom Components 2004 LTD
6PIN ZERO CROSSING TRIAC OUTPUT,
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOC3032XSM
ActiveIsocom Components 2004 LTD
6PIN ZERO CROSSING TRIAC OUTPUT,
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOC3032XSM |
|---|---|
| Approval Agency | UL, VDE |
| Current - DC Forward (If) (Max) | 50 mA |
| Current - Hold (Ih) | 400 µA |
| Current - LED Trigger (Ift) (Max) [Max] | 10 mA |
| Mounting Type | Surface Mount |
| Number of Channels | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Output Type | Triac |
| Package / Case | 6-SMD, Gull Wing |
| Static dV/dt (Min) [Min] | 600 V/µs |
| Voltage - Off State | 250 V |
| Zero Crossing Circuit | True |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 1.30 | |
| 10 | $ 0.82 | |||
| 25 | $ 0.69 | |||
| 100 | $ 0.54 | |||
| 250 | $ 0.47 | |||
| 500 | $ 0.43 | |||
| 1000 | $ 0.39 | |||
| 2500 | $ 0.35 | |||
| 5000 | $ 0.33 | |||
Description
General part information
MOC3032XSM
Optoisolator Triac Output 5000Vrms 1 Channel
