L513ET-E
ActiveAmerican Opto Plus LED
LED RED 5MM T/H
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
L513ET-E
ActiveAmerican Opto Plus LED
LED RED 5MM T/H
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | L513ET-E |
|---|---|
| Color | Red |
| Current - Test | 30 mA |
| Lens Color | Amber |
| Lens Size | T-1 3/4 |
| Lens Size | 5 mm |
| Lens Style | Round with Domed Top |
| Millicandela Rating | 30 mcd |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package | 5 mm |
| Viewing Angle | 30 ° |
| Voltage - Forward (Vf) (Typ) | 2.1 V |
| Wavelength - Peak | 635 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.35 | |
| 10 | $ 0.22 | |||
| 100 | $ 0.17 | |||
| 500 | $ 0.11 | |||
| 1000 | $ 0.09 | |||
Description
General part information
L513ET-E
Red LED Indication - Discrete 2.1V Radial
