MB3024S-05ERW
ActiveMicroPower Direct
DC-DC 24VIN 5VOUT 30W 1X2 REGULA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MB3024S-05ERW
ActiveMicroPower Direct
DC-DC 24VIN 5VOUT 30W 1X2 REGULA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MB3024S-05ERW |
|---|---|
| Applications | Industrial |
| Approval Agency | UKCA, CE |
| Current - Output (Max) [Max] | 6 A |
| Efficiency | 88 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 80 ¯C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 30 W |
| Size / Dimension [x] | 50.8 mm |
| Size / Dimension [x] | 2 in |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [z] | 0.47 " |
| Size / Dimension [z] | 11.8 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 18.75 | |
| 10 | $ 18.00 | |||
| 25 | $ 17.45 | |||
| 50 | $ 16.90 | |||
| 100 | $ 16.35 | |||
Description
General part information
MB3024S-05ERW
Isolated Module DC DC Converter 1 Output 5V 6A 18V - 36V Input
