CARD-0512M
ActiveDiwell Electronics
DC DC CONVERTER +/-12V 2W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CARD-0512M
ActiveDiwell Electronics
DC DC CONVERTER +/-12V 2W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CARD-0512M |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 84 mA |
| Current - Output (Max) | 84 mA |
| Efficiency | 59 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 24-DIP Module |
| Package / Case | 12 Leads |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 31.8 mm |
| Size / Dimension [x] | 1.25 " |
| Size / Dimension [y] | 0.8 in |
| Size / Dimension [y] | 20.3 mm |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 5.5 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 12 V |
| Voltage - Output 2 | -12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.33 | |
| 5 | $ 3.96 | |||
| 10 | $ 3.81 | |||
| 25 | $ 3.62 | |||
| 50 | $ 3.48 | |||
| 100 | $ 3.35 | |||
| 250 | $ 3.19 | |||
| 500 | $ 3.06 | |||
Description
General part information
CARD-0512M
Isolated Module DC DC Converter 2 Output 12V -12V 84mA, 84mA 4.5V - 5.5V Input
