DSG815
ActiveRIGOL Technologies, Inc
RF SIGNAL SOURCE FROM 9KHZ-1.5GHZ, WITH -100DBC/HZ PHASE NOISE,+13DBM TO -110DBM POWER OUTPUT, AND AMPLITUDE ACCURACY < 0.5DB
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DSG815
ActiveRIGOL Technologies, Inc
RF SIGNAL SOURCE FROM 9KHZ-1.5GHZ, WITH -100DBC/HZ PHASE NOISE,+13DBM TO -110DBM POWER OUTPUT, AND AMPLITUDE ACCURACY < 0.5DB
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | DSG815 |
|---|---|
| Display Type | TFT - Color LCD |
| Frequency - Max [Max] | 1.5 GHz |
| Function | Sweep |
| Number of Channels | 1 |
| Supply Voltage [Max] | 240 V |
| Supply Voltage [Min] | 100 V |
| Type | Pulse Generator |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 1 | $ 2099.00 | |
Description
General part information
DSG815
1.5 GHz Sweep Pulse Generator 1 Channel Display Type TFT - Color LCD
