CM200DX-24S
UnknownPowerex Inc.
IGBT MOD 1200V 200A 1500W
Deep-Dive with AI
Search across all available documentation for this part.
CM200DX-24S
UnknownPowerex Inc.
IGBT MOD 1200V 200A 1500W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CM200DX-24S |
|---|---|
| Configuration | Half Bridge |
| Current - Collector (Ic) (Max) [Max] | 200 A |
| Current - Collector Cutoff (Max) [Max] | 1 mA |
| Input | Standard |
| Input Capacitance (Cies) @ Vce | 20 nF |
| Mounting Type | Chassis Mount |
| NTC Thermistor | True |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Power - Max [Max] | 1500 W |
| Supplier Device Package | Module |
| Vce(on) (Max) @ Vge, Ic | 2.15 V |
| Voltage - Collector Emitter Breakdown (Max) [Max] | 1200 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
CM200DX-24S
IGBT Module Half Bridge 1200 V 200 A 1500 W Chassis Mount Module
