NW-PA-C-20-R01
ActiveNuWaves RF Solutions
IC RF AMP GPS 4.4GHZ-4.9GHZ
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NW-PA-C-20-R01
ActiveNuWaves RF Solutions
IC RF AMP GPS 4.4GHZ-4.9GHZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NW-PA-C-20-R01 |
|---|---|
| Current - Supply | 3.6 A |
| Frequency [Max] | 4.9 GHz |
| Frequency [Min] | 4.4 GHz |
| Gain | 43 dB |
| Mounting Type | Connector Mount |
| P1dB | 33 dBm |
| Package / Case | Module, SMA Connectors |
| RF Type | General Purpose |
| Test Frequency | 4.4 GHz |
| Voltage - Supply [Max] | 32 VDC |
| Voltage - Supply [Min] | 27 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 6919.00 | |
Description
General part information
NW-PA-C-20-R01
RF Amplifier IC General Purpose 4.4GHz ~ 4.9GHz
Documents
Technical documentation and resources
