IW-G35M-11EG-4E004G-E008G-BIA
ActiveiWave Global
ZU11EG (-1 SPEED) MPSOC SOM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
IW-G35M-11EG-4E004G-E008G-BIA
ActiveiWave Global
ZU11EG (-1 SPEED) MPSOC SOM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | IW-G35M-11EG-4E004G-E008G-BIA |
|---|---|
| Co-Processor | ARM® Mali 400 MP2 |
| Connector Type | 2 x 240 Pin |
| Core Processor | ARM® Cortex™-M7(x1), ARM® Cortex®-A53 (x4) |
| Flash Size | 8 GB |
| Module/Board Type | MPU, FPGA |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| RAM Size | 4GB from PL, 4GB from PS |
| Size / Dimension [x] | 4.33 in |
| Size / Dimension [x] | 110 mm |
| Size / Dimension [y] | 75 mm |
| Size / Dimension [y] | 2.95 in |
| Speed | 600 MHz |
| Speed | 1.5 GHz |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3453.00 | |
Description
General part information
IW-G35M-11EG-4E004G-E008G-BIA
Zynq® UltraScale+™ Embedded Module ARM® Cortex®-A53 (x4), ARM® Cortex™-M7(x1) ARM® Mali 400 MP2 1.5GHz, 600MHz 4GB from PS, 4GB from PL 8GB eMMC
