12.86517
ActiveGeyer Electronic America, Inc.
CYSTAL 24.0MHZ 10PF SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
12.86517
ActiveGeyer Electronic America, Inc.
CYSTAL 24.0MHZ 10PF SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 12.86517 |
|---|---|
| ESR (Equivalent Series Resistance) | 80 Ohm |
| Frequency | 24 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 50 ppm |
| Height - Seated (Max) [Max] [z] | 0.022 in |
| Height - Seated (Max) [Max] [z] | 0.55 mm |
| Load Capacitance | 10 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Package / Case | 4-SMD, Flat Leads |
| Size / Dimension [x] | 0.098 " |
| Size / Dimension [x] | 2.5 mm |
| Size / Dimension [y] | 2 mm |
| Size / Dimension [y] | 0.079 in |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.48 | |
| 10 | $ 0.40 | |||
| 50 | $ 0.36 | |||
| 100 | $ 0.32 | |||
| 500 | $ 0.31 | |||
| Digi-Reel® | 1 | $ 0.48 | ||
| 10 | $ 0.40 | |||
| 50 | $ 0.36 | |||
| 100 | $ 0.32 | |||
| 500 | $ 0.31 | |||
| Tape & Reel (TR) | 1000 | $ 0.26 | ||
| 3000 | $ 0.24 | |||
| 5000 | $ 0.23 | |||
| 10000 | $ 0.23 | |||
Description
General part information
12.86517
24 MHz ±50ppm Crystal 10pF 80 Ohms 4-SMD, Flat Leads
