SKA470M160
ActiveMALLORY
CAP ALUM 47UF 20% 160V AXIAL TH
Deep-Dive with AI
Search across all available documentation for this part.
SKA470M160
ActiveMALLORY
CAP ALUM 47UF 20% 160V AXIAL TH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SKA470M160 |
|---|---|
| Applications | General Purpose |
| Capacitance | 47 µF |
| ESR (Equivalent Series Resistance) | 5.65 Ohm |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Can, Axial |
| Polarization | Polar |
| Ripple Current @ High Frequency | 225 mA |
| Ripple Current @ Low Frequency | 180 mA |
| Size / Dimension [diameter] | 13 mm |
| Size / Dimension [diameter] | 0.512 in |
| Size / Dimension [x] | 30 mm |
| Size / Dimension [x] | 1.181 in |
| Tolerance | 20 % |
| Voltage - Rated | 160 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 0.55 | |
Description
General part information
SKA470M160
47 µF 160 V Aluminum Electrolytic Capacitors Axial, Can 5.65Ohm @ 120Hz 2000 Hrs @ 85°C
