UPO1102CS
ActiveUni-Trend Technology US Inc
DIGITAL OSCILLOSCOPES 100MHZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UPO1102CS |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 2 Analog |
| Display Type | LCD |
| Includes | USB/RS232 Cable |
| Input Impedance | 16 pF, 1 MΩ |
| Interface | USB, RS232 |
| Memory Size | 56 Mpts |
| Probe Type | Passive (2) |
| Rise Time (Typ) | 3.5 ns |
| Sampling Rate (Per Second) | 1 G |
| Type | Bench, Digital |
| Voltage - Input (Max) [Max] | 400 V |
| Voltage - Supply [Max] | 240 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 1 | $ 275.00 | |
Description
General part information
UPO1102CS
100 MHz Bench, Digital Oscilloscopes RS232, USB Interface LCD Display 2 Analog Channel 400V Record, Playback
