SG-8018CB 67.6000M-TJHPA0

Active

EPSON

XTAL OSC XO 67.6000MHZ CMOS SMD

Search across all available documentation for this part.

Active

EPSON

XTAL OSC XO 67.6000MHZ CMOS SMD

Technical Specifications

Parameters and characteristics for this part

Specification	SG-8018CB 67.6000M-TJHPA0

Base Resonator	Crystal
Current - Supply (Disable) (Max) [Max]	3.5 mA
Current - Supply (Max) [Max]	8.1 mA
Frequency	67.6 MHz
Frequency Stability	50 ppm
Function	Enable/Disable
Height - Seated (Max) [Max] [z]	1.3 mm
Height - Seated (Max) [Max] [z]	0.051 in
Mounting Type	Surface Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Output	CMOS
Package / Case	4-SMD, No Lead
Size / Dimension [x]	0.197 in
Size / Dimension [x]	5 mm
Size / Dimension [y]	0.126 "
Size / Dimension [y]	3.2 mm
Type	XO (Standard)
Voltage - Supply [Max]	3.63 V
Voltage - Supply [Min]	1.62 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1000	$ 0.64

General part information

67.6 MHz XO (Standard) CMOS Oscillator 1.62V ~ 3.63V Enable/Disable 4-SMD, No Lead
