1-1614-352138
ActiveSchaltbau
C310S/150 24I-V2 - AC AND DC UP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-1614-352138 |
|---|---|
| Coil Current | 110 mA |
| Coil Power | 2.6 W |
| Coil Resistance | 1.6 kOhms |
| Coil Voltage [Max] | 36 VDC |
| Coil Voltage [Min] | 9.5 VDC |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 150 A |
| Features | Auxillary Contacts, Economizer |
| Must Operate Voltage | 9.5 VDC |
| Must Release Voltage | 7.95 VDC |
| Operate Time | 20 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Release Time | 13 ms |
| Switching Voltage | 96 VDC |
| Termination Style | Busbar |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 179.00 | |
Description
General part information
1-1614-352138
C310S/150 24I-V2 - AC AND DC UP
Documents
Technical documentation and resources
No documents available
