CHNR5040-151M-00000
ActiveChipsen
FIXED IND 150UH 600MA 975 MOHM S
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CHNR5040-151M-00000
ActiveChipsen
FIXED IND 150UH 600MA 975 MOHM S
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CHNR5040-151M-00000 |
|---|---|
| Current - Saturation (Isat) | 650 mA |
| Current Rating (Amps) | 600 mA |
| DC Resistance (DCR) | 975 mOhm |
| Height - Seated (Max) [Max] | 0.157 in |
| Height - Seated (Max) [Max] | 4 mm |
| Inductance | 150 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.197 in |
| Size / Dimension [x] | 5 mm |
| Size / Dimension [y] | 5 mm |
| Size / Dimension [y] | 0.197 " |
| Supplier Device Package | 2-SMD |
| Tolerance | 20 % |
| Type | Wirewound |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1500 | $ 0.10 | |
| 3000 | $ 0.09 | |||
| 7500 | $ 0.09 | |||
| 15000 | $ 0.08 | |||
Description
General part information
CHNR5040-151M-00000
150 µH Shielded Wirewound Inductor 600 mA 975mOhm Nonstandard
