TIL111X
ActiveIsocom Components 2004 LTD
6PIN TRANSISTOR DETECTOR, SINGLE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TIL111X
ActiveIsocom Components 2004 LTD
6PIN TRANSISTOR DETECTOR, SINGLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TIL111X |
|---|---|
| Current - DC Forward (If) (Max) [Max] | 60 mA |
| Current - Output / Channel | 50 mA |
| Current Transfer Ratio (Min) [Min] | 20 % |
| Input Type | DC |
| Mounting Type | Through Hole |
| Number of Channels | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 6-DIP |
| Package / Case | 0.3 in |
| Package / Case | 7.62 mm |
| Rise / Fall Time (Typ) [custom] | 2 µs |
| Rise / Fall Time (Typ) [custom] | 2 µs |
| Supplier Device Package | 6-DIP |
| Vce Saturation (Max) [Max] | 400 mV |
| Voltage - Isolation | 5300 Vrms |
| Voltage - Output (Max) [Max] | 30 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 0.79 | |
| 10 | $ 0.49 | |||
| 25 | $ 0.41 | |||
| 100 | $ 0.32 | |||
| 250 | $ 0.27 | |||
| 500 | $ 0.24 | |||
| 1000 | $ 0.22 | |||
| 2500 | $ 0.20 | |||
| 5000 | $ 0.18 | |||
Description
General part information
TIL111X
Optoisolator Transistor with Base Output 5300Vrms 1 Channel 6-DIP
