AGA308
ActivePelonis Technologies
FAN MICRO FAN 30X8MM 5VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
AGA308
ActivePelonis Technologies
FAN MICRO FAN 30X8MM 5VDC WIRE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AGA308 |
|---|---|
| Air Flow | 2.6 CFM |
| Air Flow | 0.074 mł/min |
| Approval Agency | CE |
| Bearing Type | Axial Groove |
| Fan Type | Micro Fan |
| Features | Auto Restart, Locked Rotor Protection, Polarity Protection |
| Ingress Protection | IP58 - Dust Protected, Waterproof |
| Noise | 22 dB(A) |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -10 °C |
| Operating Temperature [Min] | -10 °C |
| RPM | 6200 RPM |
| Size / Dimension [diameter] | 30 mm |
| Termination | 2 Wire Leads |
| Voltage - Rated | 5 V |
| Weight | 0.008 lb |
| Weight | 3.63 g |
| Width [y] | 8 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 16.96 | |
| 11 | $ 15.83 | |||
| 26 | $ 14.84 | |||
| 51 | $ 13.57 | |||
| 101 | $ 11.50 | |||
Description
General part information
AGA308
Fan Micro Fan 5VDC Round - 30mm Dia Axial Groove 2.6 CFM (0.074mł/min) 2 Wire Leads
Documents
Technical documentation and resources
No documents available
